Edon TIG 200 AC/DC Pulse Inverter Welding Machine

Edon TIG 200 AC/DC Pulse Inverter Welding Machine is a high precision welding solution designed for TIG and MMA applications. It is built for fabricators and technicians who require full control when working with different metals including aluminum, stainless steel, and mild steel.

The machine features full AC/DC capability. DC mode supports welding of steel, stainless steel, and copper. AC mode is designed for aluminum welding, helping break oxide layers and deliver clean, strong welds. This makes it a complete solution for multi material fabrication.

Pulse TIG function allows precise heat control by cycling between high and low current. This reduces distortion, improves weld appearance, and gives better control on thin materials. It is ideal for detailed fabrication and finishing work.

The digital control panel allows adjustment of key welding parameters including current, pulse frequency, duty cycle, upslope, downslope, and gas flow timing. This ensures consistent weld quality and repeatable results.

High frequency start enables non contact arc ignition, preventing contamination and improving weld cleanliness. The machine also supports 2T and 4T trigger modes for better control during short and long welds.

Key Features

• AC/DC TIG welding for aluminum and steel
• Pulse TIG for heat control and precision welding
• TIG and MMA dual functionality
• High frequency arc start for clean ignition
• Digital control panel with full parameter adjustment
• 2T and 4T trigger modes for better operation control
• Stable arc with inverter technology
• Compact and portable design
• Efficient cooling system for continuous use

AC/DC Welding Functions

• AC Mode for aluminum welding with oxide cleaning action
• DC Mode for stainless steel, mild steel, and copper
• Adjustable AC balance for cleaning versus penetration control
• Adjustable AC frequency for arc focus and stability
• Pulse frequency control for heat input management
• Peak and base current adjustment for weld consistency

Specifications

• Model: TIG-200ACDC
• Welding Type: TIG AC/DC, Pulse TIG, MMA
• Input Voltage: 220V
• Frequency: 50/60Hz
• Input Power: Approx 4.5 KVA
• Duty Cycle: 60 percent at 40°C
• Output Current Range: Up to 200A
• Control Mode: Digital
• Protection Class: IP21S
• Insulation Class: F

Gas Requirement

• TIG welding uses Argon gas
• Gas is sold separately
• MMA welding does not require gas

Applications

• Aluminum fabrication
• Stainless steel welding
• Precision metal work
• Automotive and bodywork repairs
• Pipe and thin sheet welding
• Workshop and industrial use
